Kona Sutra LTD

Kona Sutra LTD
  • Color: Gloss Metallic Champagne
$2,399.00
Color: Gloss Metallic Champagne
Size: Select size
Please select options Unavailable

Details

The Sutra LTD is one of those bikes that just changes everything. You thought you were a mountain biker, but you find yourself sneaking off on adventures on the LTD. You thought you were a roadie, but find yourself riding singletrack when no one else is looking. That’s the best part about the Sutra LTD—it broke the mold of what a bike has to be. The Cromoly steel frame holds an 11-speed SRAM Rival 1 drivetrain and brakes with 160mm rotors, providing ample power to climb and stop the bike. Velo Shock-proof bar tape keeps the vibrations down and WTB Venture TCS 700x50c tires make quick work of tricky terrain.

Kona Cromoly
Very few materials offer as much shock absorption, durability, and supple-ride characteristics as steel. We’ve never strayed from cycling’s original material and have worked tirelessly to adapt, refine and innovate Kona Cromoly framesets as rider demands continue to evolve.

Tubeless Compatible Rims
Tubeless rims allow for tires with more puncture resistance; the ability to run lower tire pressure, which provides better tire grip on the trail; lower rolling resistance; and weight savings over traditional tube and tire systems.

12x142mm Axle
12x142mm, 12x148, and 12x157 rear axle standards provide two major advantages to the Kona rider: the 12mm diameter of the rear axle provides the rear hub and frame with a stiff interface, while the 142/148/157mm outer diameter of the hub allows the wheel to be quickly and properly positioned in the frame before the rear axle is inserted.

Specs

Frame Kona Cromoly Butted
Fork Kona Project Two Cromoly Disc Touring fork
Headset FSA TH848
Axles Front: 100 x 12mm thru-axle
Rear: 142 x 12mm thru-axle
Rims/Wheels WTB KOM Light Team i25 TCS 2.0
Hubs Formula
Spokes Stainless Black 14g
Tires WTB Venture TCS 700c x 50
Crankset RaceFace Aeffect
Chainrings 36T Narrow/Wide
Bottom Bracket RaceFace 73mm
Chain SRAM PC1110
Rear Derailleur SRAM Rival 1
Cassette/Rear Cogs SRAM XG1150 10-42t 11spd
Shifters SRAM Rival 1
Handlebars Kona Road
Tape/Grips Velo Shock-Proof Bar Tape
Stem Kona Road Deluxe
Brake Levers SRAM Rival 1 HRD
Brakes SRAM Rival 1 Flat mount w/SRAM Centerline 160mm rotors
Saddle WTB SL8
Seat Post Kona Deluxe Thumb w/Offset 27.2mm

* Subject to change without notice.

Part Numbers

Option UPC MPN
Gloss Metallic Champagne / 48cm 841073140619 B21SUL48
Gloss Metallic Champagne / 50cm 841073140626 B21SUL50
Gloss Metallic Champagne / 52cm 841073140633 B21SUL52
Gloss Metallic Champagne / 54cm 841073140640 B21SUL54
Gloss Metallic Champagne / 56cm 841073140657 B21SUL56
Gloss Metallic Champagne / 58cm 841073140664 B21SUL58
